Why use the SIP building system?
Structural insulated panels (SIPs)
Structural insulated panels (SIPs) are a high performance building system for residential and commercial construction. The panels consist of an insulating foam core sandwiched between two structural facings, typically oriented strand board (OSB). SIPs are manufactured under factory controlled conditions.
Advantages of the Kingspan TEK SIP building system
Excellent over all thermal performance with low U values, reduced thermal bridging and excellent air tightness, these combined will reduce the need for additional measures such as PV’s, ground/air source heat pumps.
TEK system has a suite of Psi Values for the non-repeat junctions with the majority being better than Accredited Construction details.
Less reliant on follow on trades to achieve the above as within the fabric of the structure.
BBA & European Technical approval with a minimum life expectancy of 60 years.
Thinner wall construction enabling greater habitable floor space/reduced over site.
15mm OSB/3 panels faces providing a more robust construction up to 4 storeys as a freestanding structure (most other SIPS are only to 2 storesys) and fixing of heavy loads to the face of the panel.
Lighter construction reducing foundation requirements.
Recognised by all major building warranty providers and Council of Mortgage lenders.
Off-site manufacturer leading to better quality of construction.
Continuous manufacturing line with panels up to 7.5m in length.
Reduced construction times leading to reduced site prelims and faster return on the clients investment.
Reduced site waste
Technical back up of Kingspan with U values and Condensation risk analyses.
Insulation HCFC & CFC free, Ozone depletion of zero and a GWP of less than 5 resulting ib the TEK panel being rated as a A or A+ product under the BRE green guide.
Only requires 1 layer of 12.5mm Fire Check plasterboard to achieve 60 mins fire performance.
Robust connection detail between the TEK external wall and party wall.
